Cutting Tools

Cable Cutter Design

Cutting a cable is the first in a series of operations with the aim of making an electrical connection. To cut cables of different shapes, materials and diameters properly, the right cable cutting tools must be used. There are different tools for thin, fine-wire conductors, precise right-angled cutting of ribbon cables and cutting thick cables. It should be possible to cleanly cut the cables without undue effort.

P/N 712 100 3

  • For cutting single-stranded, multi-stranded, fine-wire aluminum and copper cables
  • Cuts smooth and clean without crushing
  • Forged cutting head, high-strength aluminum tube arms
  • Adjustable screw hinge
  • Blade made of special steel, hardened
  • Replaceable cutting head
  • Not suitable for steel wire

P/N 502 037 6

  • Cuts tubes clean and burr free
  • For composite and plastic pipes
  • Cuts up to 1 Inch
  • Compact design
  • Ergonomically designed handles
  • Lightweight tool (glass fiber reinforced  plastic body)

P/N 700 015 3

  • Suitable for universal use for cutting, and dismantling
  • According to the aerospace standard AS6173/3 FEDERAL SUPPLY CLASS 5120
  • Sharp, hardened, precision-ground blades
  • Clean and smooth cut without crushing or deformation
  • No crushing, no deformation
  • With guard
  • Adjustable joint screw
  • Guard prevents operators fingers being pinched
  • Material: special tool steel, forged

P/N 700 038 3

  • For cutting single-stranded, multi-stranded, fine-wire aluminum and copper cables
  • Comfortable work thanks to ratchet action and low weight
  • Forged cutting head, high-strength aluminum tube arms
  • Two-component handles can be adjusted based on working conditions. Adjusts from 15 ½ - 23 ½ inches
  • Replaceable cutting head
  • Not suitable for steel wire

Award winning tool!

P/N 8007 5003 3

  • Special tool for cutting data cable
  • Dismantling of outer sheath by means of a shaped blade
  • No damage of shield or wire
  • Attachment for easy opening resp. removal of twisted pair shield
  • Two different cutting ranges for:
    • Outer shield, twisted pair shield and wire
    • Plastic fiber
  • Small and compact design
  • Ergonomically designed two-component handles
  • Convenient operation
  • Material: special tool steel
  • Surface: burnished

P/N 700 020 3 (Plastic Coated)

P/N 700 020 36 (Reinforced Plastic Grips)

  • For cutting copper and aluminum cable, single and multiple wire
  • Not suitable for steel wire and hard-drawn copper conductors
  • Guard prevents operators fingers being pinched
  • No crushing, no deformation
  • Initial and final cut (1st and 2nd blades) allow cable with a diameter of up to max. 20 mm Ø (1 inch) to be cut
  • Sharp, hardened, precision-ground blades
  • Easy, clean cut with one-hand operation
  • Adjustable joint screw, self-locking
  • Not suitable for steel wire
  • Material: special tool steel, forged

P/N 712 060 3

  • For cutting single-stranded, multi-stranded, fine-wire aluminum and copper cables
  • Cuts smooth and clean without crushing
  • Forged cutting head, high-strength aluminum tube arms
  • Adjustable screw hinge
  • Not suitable for steel wire
  • Blade made of special steel, hardened
  • Replaceable cutting head

P/N 8000 1000 3

  • For cutting Kevlar ® fibers (used as strain relief in fiber optic cable)
  • Toothed and ground blades
  • Rivet joint
  • Ergonomically designed two-components handles
  • Not to be used for other materials



P/N 8007 5004 6 RT

This tool is especially designed for opening the heads of cable ties without harming bundled items. It works great with all cable tie strap widths.

  • Light weight
  • 2 component handles
  • For areas with limited space
  • Spring loaded
  • Designed for Maintenance and Repair
  • Recommended by the aircraft industry

P/N 700 027 2

  • Easy clean cut due to new improved blade geometry
  • Short design, low weight
  • Forged cutting head, handles made of special aluminum-pipe
  • Adjustable screw joint
  • Not suitable for steel wire or wire cable
  • Material: special tool steel, forged
  • For cutting copper and aluminum cable, single and multiple wire
  • Not suitable for steel wire and wire ropes

Compact Cable Cutter with Opening Spring (RGO)

P/N 700 016 36

  • Suitable for universal use for cutting and dismantling
  • According to the aerospace standard AS6173/3 FEDERAL SUPPLY CLASS 5120
  • Automatic reopening through spring-loaded handles
  • Easy and clean cutting performance through  precision-ground blades
  • Single and multiple wire
  • Clean and smooth cut without crushing or deformation
  • Lock closure and distance stops for high safety comfort
  • Easy cutting with one-hand operation
  • Guard prevents operators fingers being pinched
  • Material: special tool steel, forged
  • Not suitable for steel wire

P/N 625 41551 3

RENNSTEIG offers a new version of the terminal cut off tool (called Singulator) to cut terminals from a reel with a thickness of up to 0.7 mm (0.03"). This item will be available as complete Hand Tool, that means Crimp System Tool with pre-assembled cutting unit. Or as separate unit for all customers who already own our crimp tool frame.
